200W Single Crystal Solar Panel -- 153067030mm

This monocrystalline solar panel has a rated power of 200W and measures 1530×670×30mm. It utilizes monocrystalline silicon cell technology and boasts high photovoltaic conversion efficiency. The panel is covered with high-transmittance, low-iron tempered glass to enhance light absorption and mechanical strength. The backsheet is made of weather-resistant TPE, effectively resisting moisture and UV rays. The anodized aluminum alloy frame is corrosion-resistant and can withstand high wind and snow loads. The junction box is IP67-rated, dustproof and waterproof, and supports bypass diodes to reduce the impact of partial shadows on power generation. It is suitable for off-grid systems, small-scale home power generation, and commercial photovoltaic projects.

PREV：240W Single Crystal Solar Panel -- 1520*760*30mm NEXT：180W single crystal solar panel -- 1520*580*30mm

Product Parameters

Model	SZ-200-M
Rated power	200W
Maximum power current	8.21A
Maximum power voltage	24.36V
Open-circuit voltage	28.56V
Short-circuit current	8.71A
Maximum system voltage	500V
Output tolerance	0~+3%
Cable (MC4)	700mm/2.5mm²
Rated value of junction box	≥IP67
Solar cell	210105--143
Operating temperature	-40°℃~+80°℃
Module size	153067030mm
Weight (net weight/gross weight)	10.2/12.2kg
