160W single crystal solar panel -- 123067030mm

This product is a 160W monocrystalline solar panel with dimensions of 1230×670×30mm. It utilizes monocrystalline silicon cell technology and boasts high photovoltaic conversion efficiency. The panel is covered in high-strength tempered glass and features a corrosion-resistant aluminum alloy frame. It can withstand typical wind and snow loads, making it suitable for a variety of outdoor environments.

Its operating voltage range is moderate, making it compatible with mainstream off-grid systems and energy storage control equipment. The panel's junction box meets IP67 protection, ensuring stable operation in humid and dusty conditions. It is widely applicable in applications such as home backup power, agricultural irrigation, communication base stations, and outdoor surveillance.

The overall structure utilizes a laminated encapsulation process, effectively enhancing the panel's mechanical strength and long-term durability. It also supports natural heat dissipation, helping maintain stable performance across the operating temperature range.

PREV：180W single crystal solar panel -- 1520*580*30mm NEXT：150W Monocrystalline Solar Panel -- 1045*768*30mm

Product Parameters

Model	SZ-160-M
Rated power	160W
Maximum power current	8.36A
Maximum power voltage	19.14V
Open-circuit voltage	22.44V
Short-circuit current	8.87A
Maximum system voltage	500V
Output tolerance	0~+3%
Cable (MC4)	700mm/2.5mm²
Rated value of junction box	≥IP67
Solar cell	210105--113
Operating temperature	-40°C~+80°℃
Module size	123067030mm
Weight (net weight/gross weight)	8.9/10.0kg
