Colored Steel Tile Mounting Systems

The color steel tile flat-lay bracket is a mounting component specifically designed for color steel tile roofing systems, suitable for installation on flat or low-slope roofs. Made of galvanized steel or stainless steel, the bracket offers excellent corrosion resistance and durability. Its structural design conforms to the contours of the color steel tile and is mechanically secured to the roof purlins, ensuring installation stability and overall structural safety.

This product is suitable for roofing applications in various industrial buildings, storage facilities, and large public buildings. It effectively accommodates thermal expansion and contraction caused by temperature fluctuations, maintaining the long-term flatness and sealing of the roof system. Installation eliminates the need to drill holes in the existing color steel sheet, helping to maintain the roof's leak-proof properties.

Typical specifications vary depending on tile type and purlin spacing. Common thicknesses range from 1.5mm to 2.5mm, and the surface treatment is typically hot-dip galvanized or zinc-aluminum coated to meet the weathering requirements of various environmental conditions.

PREV：Concrete Roof Cement Foundation Mounting Systems NEXT：Asphalt Shingle Roof Mounting Systems

Product Parameters

Arrangement method	Vertical or horizontal
Main material	Aluminum alloy
Installation angle	Parallel to the roof
Surface treatment	Anodizing
Wind pressure	≤45m/s
Snow pressure	≤50cm
